Summit Family Switches Hardware Installation Guide
341
CHAPTER
9
Replacing AC Power Supplies in
Summit Family Switches
This chapter describes how to replace AC power supplies in a Summit X460, X480, X650, or X670 series
switch and how to remove EPS series AC redundant power supplies.
This chapter includes the following sections:
● Replacing a Summit 300 W AC Power Supply on page 341
● Replacing a Summit 450 W or 550 W AC Power Supply on page 344
● Replacing a Summit 750 W AC Power Supply on page 347
● Replacing a Summit X850 W AC Power Supply on page 350
● Removing EPS Series AC Redundant Power Supplies on page 352
NOTE
Read the information in this chapter thoroughly before attempting to replace one of the listed
Summit X650 components.
Replacing a Summit 300 W AC Power Supply
The Summit 300 W AC power supplies are compatible with the Summit X460 series non-PoE switches.
These switches have two bays for hot-swappable power supplies. In a switch with a redundant power
configuration, you can replace one Summit AC power supply without powering down the switch.
You need the following tools and materials to replace a Summit 300 W AC power supply:
● Thermal protective gloves
● AC power cord, if you will not be re-using the cord from the removed power supply
An AC power cord is not included with a Summit AC power supply. You must obtain a power
supply cord that meets the requirements listed under
“Power Cord Requirements for AC-Powered
Switches and AC Power Supplies” on page 500
.
To replace a Summit 300 W AC power supply:
1 Disconnect the AC power cord from the wall outlet and from the power supply.
2 Note the orientation of the installed power supply.
