Summit X350 Series Switches
Summit Family Switches Hardware Installation Guide
427
Summit X350 Series Switches
The Summit X350 series includes the following switches:
● Summit X350-24t
● Summit X350-48t
Table 82: Summit X350 Series Switch Technical Specifications
Physical Dimensions
Summit X350-24t switch Height: 1.73 inches (4.4 cm)
Width: 17.35 inches (44.1 cm)
Depth: 15.3 inches (38.7 cm)
Summit X350-48t switch Height: 1.73 inches (4.4 cm)
Width: 17.35 inches (44.1 cm)
Depth: 17.0 inches (43.2 cm)
Weight
Summit X350-24t switch 13.75 lb (6.24 kg)
Summit X350-48t switch 15.75 lb (7.14 kg)
Packaged Dimensions
Summit X350-24t switch
Summit X350-48t switch
Height: 5.9 inches (15 cm)
Width: 22.4 inches (57cm)
Depth: 21.7 inches (55 cm)
Packaged Weight
Summit X350-24t switch 18.7 lb (8.5 kg)
Summit X350-48t switch 20.4 lb (9.3kg)
Summit X350-24t Power
Operational voltage range 90 to 264 V
Nominal input ratings 100 to 240 V , 50/60 Hz, 1.0 A
Input current 0.75 A @ 115 V (low-line)
0.4A @ 230 V (high-line)
Line frequency range 47 to 63 Hz
Inrush current 30 A @ 115 V, 60 A @ 230 V
Power supply cord type AC
Power supply input socket IEC 320 C14
Power cord input plug IEC 320 C13
Power cord wall plug Refer to “Power Cord Requirements for AC-Powered Switches and
AC Power Supplies” on page 500.
Power supply cord gauge 18 AWG (0.75 mm
2
) (up to 6 feet or 2 meters)
or
16 AWG (1.0 mm
2
) over 6 feet
Efficiency 80% with 60% to 100% load
Heat dissipation 75 W (256 BTU/hr)
Power consumption 75 W (256 BTU/hr)
Summit X350-48t Power
Operational voltage range 90 to 264 V
Nominal input ratings 100 to 240 V , 50/60 Hz, 1.0 A
