Installing a Summit X480 Series Switch
Summit Family Switches Hardware Installation Guide
263
Installing the Switch in a Four-Post Rack
To install the switch in a four-post rack:
1 At the back of the rack, attach a rear mounting bracket to each rear post, as shown in Figure 208.
Figure 208: Attaching Rear Mounting Brackets—Four-Post Installation
2 Attach an ESD-preventive wrist strap to your wrist and connect the metal end to an appropriate
ground point on the rack.
3 Set the switch on a secure work surface.
4 At the front of the switch, attach a rack-mounting bracket to each side as shown in Figure 209.
Position the bracket with the flange at the front edge of the switch.
Figure 209: Attaching a Front Mounting Bracket
SH_145
SH_143
