Appendix B: Technical Specifications
Summit Family Switches Hardware Installation Guide
464
Summit X480 Series Switches
The Summit X480 series includes the following switches:
● Summit X480-24x switch
● Summit X480-48x switch
● Summit X480-48t switch
Table 88: Summit X480 Series Switch Technical Specifications
Physical Dimensions
Summit X480-24x switch
Summit X480-48x switch
Summit X480-48t switch
Height: 1.73 inches (4.4 cm)
Width: 17.4 inches (44.1 cm)
Depth: 19.0 inches (48.3 cm)
VIM2-SummitStack module
VIM2-10G4X module
VIM2-SummitStack128 module
VIM2-SummitStack-V80 module
VIM3-40G4X module
Height: 1.7 inches (4.3 cm)
Width: 5.2 inches (13.2 cm)
Depth: 9.9 inches (25.2 cm)
Summit X480 fan module Height: 1.7 inches (4.3 cm)
Width: 5.2 inches (13.2 cm)
Depth: 9.9 inches (25.2 cm)
Weight
Summit X480-24x switch 20.9 lb (9.5 kg)
Summit X480-48x switch 22.7 lb (10.3 kg)
Summit X480-48t switch 21.2 lb (9.6 kg)
NOTE: Switch weights include installed fan module. They do not include installed VIM2 modules or
power supplies.
VIM2-SummitStack module 2.03 lb (0.92 kg)
VIM2-10G4X module 2.76 lb (1.25 kg)
VIM3-40G4X module 2.40 lb (1.09 kg)
VIM2-SummitStack128 module 2.05 lb (0.93 kg)
VIM2-SummitStack-V80 module 1.48 lb (0.67 kg)
Summit X480 fan module 0.45 lb (0.99 kg)
Packaged Dimensions
Summit X480-24x switch
Summit X480-48x switch
Summit X480-48t switch
Height: 6.5 inches (16.5 cm)
Width: 23.4 inches (59.3 cm)
Depth: 26.2 inches (66.5 cm)
VIM2-SummitStack module
VIM2-10G4X module
VIM2-SummitStack128 module
VIM2-SummitStack-V80 module
Height: 3.9 inches (10 cm)
Width: 9.4 inches (24.0 cm)
Depth: 15.4 inches (39 cm)
Packaged Weight
Summit X480-24x switch 20.94 lb (9.5 kg)
Summit X480-48x switch 22.7 lb (10.3 kg)
Summit X480-48t switch 21.2 lb (9.6 kg)
VIM2-SummitStack module 2.0 lb (0.92 kg)
VIM2-10G4X module 2.75 lb (1.25 kg)
VIM3-40G4X module 3.46 lb (1.57 kg)
