Chapter 3: Summit Option Cards and Versatile Interface Modules
Summit Family Switches Hardware Installation Guide
162
Summit XGM2-2sf Option Card
The XGM2-2sf option card allows you to add one or two 10-gigabit SFP+ modules to the following
switches:
● Summit X350 series switch, running ExtremeXOS 12.2.1 or later
● Summit X450a series switch, running ExtremeXOS 12.2.1 or later
● Summit X450e-24p or X450e-48p switch, running ExtremeXOS 12.2.1 or later
● Summit X450e-24t or X450e-48t switch, running ExtremeXOS 12.5.1 (or later)
In Summit X450a and X450e series switches, the ports on the XGM2-2sf option card can be configured
as alternate stacking ports in a SummitStack configuration that uses the SummitStack-V feature. For
more information about stacking Summit family switches, see Chapter 5.
For current information about compatible SFP+ modules and the minimum required software, refer to
the most recent version of the ExtremeXOS Hardware and Software Compatibility Matrix.
For more information about SFP+ modules, refer to the Extreme Networks Pluggable Interface Modules
Installation Guide.
Summit XGM2-2bt Option Card
The XGM2-2bt option card allows you to add two fixed 10GBASE-T ports to the following switches:
● Summit X350 series switch, running ExtremeXOS 12.2.1 or later
● Summit X450a series switch, running ExtremeXOS 12.2.1 or later
● Summit X450e-24p or X450e-48p switch, running ExtremeXOS 12.2.1 or later
● Summit X450e-24t or X450e-48t switch, running ExtremeXOS 12.5.1 (or later)
In Summit X450a and X450e series switches, the ports on the XGM2-2bt option card can be configured
as alternate stacking ports in a SummitStack configuration that uses the SummitStack-V feature. For
more information about stacking Summit family switches, see Chapter 5.
The 10GBASE-T standard (IEEE 802.3an) allows the use of standard CAT5E, CAT6, or CAT6A cable for
connection to the XGM2-2bt ports (see Table 55).
Table 55: Cable Distances for the XGM2-2bt Option Card
Cable
Type
Maximum
Distance
CAT5E 55 meters
CAT6 75 meters
CAT6A 100 meters
