Chapter 2: Summit Power Supplies

Summit Family Switches Hardware Installation Guide

150

Each EPS-C2 power supply is shipped with a special redundant power supply cord (Figure 117).

Figure 117: EPS-C2 2x7 Pin Redundant Power Cable

Collin's

ES4K027

XM_055
