MCS- 10/92 Digital Brushless AC servo drive system - Ref.0707
Non-ventilated
motors
Stall torque
Stall peak
torque
Rated
speed
Stall current
Peak
current
Rated
power
Torque
constant
Acceleration
time
Inductance
per phase
Resistance
per phase
Inertia
(1
Mass
(2
Peak torque
Mo
Nm
Mp
Nm
nN
rev/min
Io
Arms
Imax
Arms
PoW
kW
Kt
Nm/Arms
tac
ms
L
mH
R
Ω
J
kg·cm
2
P
kg
MCS-04H
Nm
MCS-08H
Nm
MCS-16H
Nm
FXM33.20A.. 7.3 36 2000 2.7 13.4 1.5 2.7 4.9 36 5.05 8.5 9.6 21.6 36.0
FXM33.30A.. 7.3 36 3000 4.1 20.0 2.3 1.8 7.4 16 2.20 8.5 9.6 14.2 28.5
FXM33.40A.. 7.3 36 4000 5.5 27.0 3.1 1.3 9.9 8.6 1.15 8.5 9.6 21.3
FXM34.20A.. 9.3 46 2000 3.4 17.0 1.9 2.7 5.0 26 3.45 11.0 11.5 21.9 43.8
FXM34.30A.. 9.3 46 3000 5.1 25.0 2.9 1.8 7.5 12 1.60 11.0 11.5 29.1
FXM34.40A.. 9.3 46 4000 6.9 34.0 3.9 1.4 10.0 6.6 0.85 11.0 11.5 21.6
FXM53.12A.. 11.9 59 1200 2.8 14.0 1.5 4.2 4.7 61 5.85 22.0 15.8 34.0 59.0
FXM53.20A.. 11.9 59 2000 4.7 23.0 2.5 2.5 7.8 22 2.15 22.0 15.8 40.5
FXM53.30A.. 11.9 59 3000 7.1 35.0 3.7 1.7 11.7 9.6 0.91 22.0 15.8 26.9
FXM54.12A.. 14.8 74 1200 3.5 17.6 1.9 4.2 4.9 44 3.70 29.0 17.8 33.8 67.7
FXM54.20A.. 14.8 74 2000 5.9 30.0 3.1 2.5 8.2 16 1.35 29.0 17.8 40.2
FXM54.30A.. 14.8 74 3000 8.7 44.0 4.7 1.7 12.3 7.3 0.64 29.0 17.8 27.2
FXM55.12A.. 17.3 86 1200 4.1 20.0 2.2 4.2 5.3 36 2.95 36.0 20.0 33.8 67.5
FXM55.20A.. 17.3 86 2000 6.7 33.0 3.6 2.6 8.8 13 1.05 36.0 20.0 41.3
FXM73.12A.. 20.8 104 1200 4.9 25.0 2.6 4.2 7.4 46 3.05 61.0 29.0 67.8
FXM73.20A.. 20.8 104 2000 8.2 41.0 4.4 2.5 12.3 17 1.10 61.0 29.0 40.6
FXM74.12A.. 27.3 135 1200 6.6 32.0 3.4 4.2 7.4 33 1.90 79.0 31.6 66.2
FXM75.12A.. 33.6 165 1200 8.0 39.0 4.2 4.2 7.4 27 1.45 97.0 36.0 67.2
(1 When adding the mechanical brake to the motor (optional) also take into account the inertia values given in the table of section “Brake Characteristics“.
(2 When adding the mechanical brake to the motor (optional) also take into account its mass values given in the table of section “Brake Characteristics“.
Note: The drive recommended to govern each motor must supply the rated current needed to obtain the rated torque from the motor.
CHARACTERISTICS TABLE OF NON-VENTILATED FXM MOTORS WITH “A” WINDING ( 400 V AC)
