Fagor MCS Series User Manual

Digital Brushless AC servo drive system - Ref.0707 MCS- 23/92
Sales reference
0
Rotating angle connectors
30
3000 rev/min
50
5000 rev/min
40
4000 rev/min
60
6000 rev/min
FKM . . .
- K
FAGOR SYNCRONOUS MOTOR
SIZE 2, 4, 6
LENGTH 1, 2, 4
RATED
SPEED
WINDING
A
400 V AC
FEEDBACK
TYPE
I0
Incremental encoder (2500 ppt)
A3
Absolute multi-turn Sincos Encoder (1.024 ppt)
E3
Sincos Encoder (1.024 ppt)
FLANGE &
SHAFT
0
With keyway (standard)
BRAKE
OPTION
0
Without brake
CONNECTION
F
220 V AC
1
Cable output without connectors
1
With standard brake (24 V DC)
1
Cilyndrical (with no keyway)
45
4500 rev/min
9
Special
SPECIAL
CONFIGURATION
K
01

ZZ
ESPECIFICATION
¡Only when it has a special configuration (K) !
Nota:
Motor with F type winding may carry an encoder with incremental I0.
The rest of feedback devices with only be available on motors with A type winding.
2
Shaft with key and seal
3
Keyless shaft with seal
