PARAMETERS, VARIABLES & COMMANDS
Notation used
<Group> <Type> <Index> where:
Group. Identifying character of the logic group to which the parameter or variable
belongs.
There are the following groups of parameters:
Type. Character identifying de type of data which the information corresponds to.
May be:
 Parameter (P) defining the system operation.
 Variable (V) that can be read and modified dynamically.
 Command (C) that carries out a specific action.
Index. Character identifying the parameter or the variable within the group to
which it belongs.
Definition examples:
SP10:
S group, (P) Parameter, (Nr) 10.
CV11:
C group, (V) Variable, (Nr) 11.
GC1:
G group, (C) Command, (Nr) 1.
GROUPS OF PARAMETERS, VARIABLES & COMMANDS
Nr FUNCTION GROUP LETTER
1
Control signals Terminal box B
2
Current control loop Current. C
3
Error diagnosis Diagnosis D
4
Encoder simulator Encoder E
5
General of the system General G
6
System hardware Hardware H
7
Analog and digital inputs Inputs I
8
Temperatures and voltages Monitoring K
9
Motor properties Motor M
10
Analog and digital outputs Outputs O
11
System communication SERCOS® Q
12
Rotor sensor properties Rotor R
13
Velocity control loop Speed: S
14
Torque and power parameters Torque T
15
Internal function generator Internal generator W
