MCS- 24/92 Digital Brushless AC servo drive system - Ref.0707
A.C. SERVODRIVE
Introduction
The MCS family is a compact speed servo drive family for controlling Synchronous AC
brushless motors.
It has two series depending on the supply voltage they can be connected to: Thus, we
will refer to:
where each of them will have the following models depending on their peak current:
For the “MCS-H” series:
For the “MCS-L:” series
General characteristics
Their main characteristics are:
MCS (H series) if the power supply voltage is 400 V AC
MCS (L series) if the power supply voltage is 220 V AC
MCS-H-04
MCS-H-08
MCS-H-16
with peak currents of 4, 8 and 16 Arms.
MCS-L-05
MCS-L-10
MCS-L-20
MCS-L-30
with peak currents of 5, 10, 20 and 30 Arms.
Three phase power supply.
Dynamic braking in case of mains failure.
PWM IGBTs.
2500-line incremental TTL encoder feedback or 1Vpp sinusoidal encoder.
Programmable encoder simulator output.
RS422 serial line.
Two logic inputs for motor control: <Speed Enable> and <Drive Enable>.
One programmable logic input.
One programmable logic output.
Two programmable logic outputs.
Integrated functions.
“On-line” parameter editing.
Integrated programming module.
Typical protections in velocity drives.
RS232, RS422 and RS485 communications interfaces.
Communication protocol: ModBus.
