Fagor MCS Series - Characteristics Plate; Sales Reference

Digital Brushless AC servo drive system - Ref.0707 MCS- 33/92
Characteristics plate
CTR, POT, VAR and FR indicate manufacturing related aspects (hardware design
versions) that are useful for technical consultations and repairs.
Sales reference
Codes of the sales reference of Fagor drives.
Examples of the specs
plate that comes with each
Fagor MCS digital drive.
MCS DIGITAL SERVO DRIVE
Example: MCS - 05 L
MODEL MCS
CURRENT
Rated Peak (0,5 s)
05
2.5 A 5 A
10
5 A 10 A
20
10 A 20 A
30
15 A 30 A
SUPPLY VOLTAGE
220 V AC
MCS DIGITAL SERVO DRIVE
Example: MCS - 04 H
MODEL MCS
CURRENT
Rated Peak (0.5 s)
04
2 A 4 A
08
4 A 8 A
16
8 A 16 A
SUPPLY VOLTAGE
400 V AC
AC SERVODRIVE
Fagor Automation S. Coop.(Spain)
MODEL:
MCS -10 L
S.N.: 22-01090003
CTR
00A
FRVAR
00A
POT
00A
INPUT : 3 X 220 VAC / 50-60 Hz
Io
Imax
5
10
Amp
Amp
W: 3,8 Kg
