Brake characteristics
FKM motors have an optional brake that applies friction to the shaft. Its purpose is to
immobilize or lock vertical axes, not to brake a moving axis. Its main characteristics
depending on the type of brake are:
Motor Holding
torque
Power
consumption
on/off
time
Unlocking
voltage margin
Inertia Mass
Units
N·m (in·lb) W (HP) ms V DC
kg·cm
2
kg (lbf)
FKM2
4.5 (39.8) 12 (0.016) 7/35 22-26 0.12 0.28 (0.62)
FKM4
9 (79.6) 18 (0.024) 7/40 22-26 0.54 0.46 (1.01)
FKM6
18 (159.3) 24 (0.032) 10/50 22-26 1.15 0.90 (1.98)
Note. Maximum speed for all of them is 1000 rev/min.
NEVER use this brake to stop a moving axis !
The brake must never exceed its maximum turning speed.
A voltage between 22 V DC and 26 V DC releases the shaft. Make
sure that no voltage over 26 V is applied that prevents the shaft from
turning.
When installing the motor, make sure that the brake fully releases
the shaft before making it turn for the first time.
