INSTALLATION ST100 Series Flow Meter
18 Fluid Components International LLC
Reference the following wiring diagrams in Appendix B for specific integral and remote mounted electronics.
Figure B-1 – Integral: AC Input Power, Analog and HART Output
Figure B-2 – Remote: AC Input Power, Analog and HART Output
Figure B-3 : Integral: DC Input Power, Analog and HART Output
Figure B-4 – Remote: DC Input Power, Analog and HART Output
Figure B-9 – Integral: AC Input Power, Modbus Output
Figure B-10 – Remote: AC Input Power, Modbus Output
Figure B-11 – Integral: DC Input Power, Modbus Output
Figure B-12 – Remote: DC Input Power, Modbus Output
Figure B-5 – Integral: AC Input Power, Foundation Fieldbus Output
Figure B-6 – Remote: AC Input Power, Foundation Fieldbus Output
Figure B-7 – Integral: DC Input Power, Foundation Fieldbus Output
Figure B-8 – Remote: DC Input Power, Foundation Fieldbus Output
Figure B-13 – Remote: 8-Conductor Interconnection Cable
Figure B-14 – Source, Pulse/Frequency Output
Figure B-15 – Sink, Pulse/Frequency Output
ST102/STP102
Figure B-16 – Flow Element Connection, Integral/Remote
Figure B-17 – Flow Element Connection, Remote
STP100/STP102
Figure B-18 – Remote: 10-Conductor Interconnection Cable
Figure B-19 – Extended Operation Mode, External Input Flow Adjust (EIA)
Figure B-20 – Extended Operation Mode, External ST100 Flow Input (EFI)
Post Installation Check
Verify all wiring connections are secure and correct to the appropriate wiring diagram. Verify the flow direction arrow on the flow element is pointing
in the right direction. Verify the mechanical process connection is secure and meets the system pressure requirements.
