FCI ST100 series User Manual

ST100 Series Flow Meter APPENDIX B - WIRING DIAGRAMS
Fluid Components International LLC 69
Figure B-19 – Extended Operation Mode, External Input Flow Adjust (EIA)
Figure B-20 – Extended Operation Mode, External ST100 Flow Input (EFI)
+
-
C01340-1-1
+
-
ST102 AC power, dual remote
interface board shown.
NOTE:
ST100 Series Interface Board (Analog)External 4-20 mA Current Source
C01126-2-1
+
-
+
-
ST102 AC power, dual remote
interface board shown, 2 places.
NOTE:
ST100 Series SLAVE ST100 Series MASTER
