FCI ST100 series User Manual

ST100 Series Flow Meter APPENDIX C - ADDITIONAL INFORMATION
Fluid Components International LLC 77
Note : The HMI interface cannot access extended operation modes. Use the ST100 configuraton software application to set up an
extended operating mode. See "Extended Operation Modes" on page 27.
HMI Menu Outline (v2.99)
 Boot Screen
 Process Data Screen
o Percentage of Flow
o Flowrate
o Totalizer
o Temperature
o Pressure
o Group
o Group Name
 Service
o Select Group
 Password
 1. Air
 2. Gas
 3. Low Flow
 4. High Flow
 5. Upset
o Alarm Ack
 Blank
 Diagnostics
o Show Faults
 Blank
o Self Test
 FE 1 IDR
 Password
 FE2 IDR
 Password
o Raw Signal
 Raw Signal FE1
 F1 Raw Signal
 RefR: 100.17
 dR: 99.89
 TCdR: 96.63
 Temp: 32.0
 Flow: 22.42
 Raw Signal FE2
 F2 Raw Signal (If Present)
o Same as FE2
 Set-up
o Instrument
 Group 1
 Flow: SFPS
 Temp: Deg F
 Pres: psi(a)
 Name: Air
 Restore
 Pipe: Rect.
 W: 1.0 in
 H: 10.0 in
o Display
 Orientation
 Select Display Orientation
 Contrast
 Select the HMI Display Contrast
o Language
 English
 LoggerSDcard
o LoggerSCcard
 Remove
 Inserted
 Device
o Serial No:
o Sales Ord No:
o Core: 1.06
o HMI: 2.99
o FE1: V1.60
o FE2: V1.60
 FE Control
o FE1: Online
 Password
 FE1 Control
 Online
 Offline
o FE2: Offline
 Password
 FE2 Control
 Online
 Offline
