7.2.4 Point address selection
The control panel supplies the address of the first addressed point. Through
the numerical keyboard it is possible to select the address of the point the
user wants to view.
Select “Ok” To view the information relative to the selected point. Select
“Canc” to return to the “Point menu”.
7.2.5 Point setting
In the “Point setting” menu there are different parameters that supply
data of the point that has been examining. Among there the “ZONE”, the
“NAME”, the “TYPE”, the “SECTION” of belonging, if “OUT OF SERVICE”,
etc…
Go on the interested line with the arrow and pressing the key “Mod.” enter
modification line. Once the user has entered modification with the
alpha/numerical keyboard of the control panel the information (to type in the
number of the selected zone, the name, …) is updated. After the
modifications are ended, press the key “Esc.”.
“Pre.” to go to the previous point;
“Next” to go to the next point.
Some data are not modifiable. Example the “Type” of point, the “SECTION”
of belonging, the “SW VERSION” etc…
To view other information relative to the point that has been examining, it is
necessary to wait a few seconds to go down with the arrows. If the point
was fault (“FAULT: YES”), it is not possible to view the further
information relative to the same point. It is first necessary to remove the
fault.
When the user wants to use the input of a input/output module, it is necessary to modify “INPUT: DISABLED”,
use the four arrows to set oneself on the line “INPUT:”, type in “Mod.” and insert the password of third level.
Input options: “FIRE ALARM”, “TECHNOLOGICAL” and “BATH”.
For other information on the single point types, see chapter PART 15.
Step-by-step, all possible command voices are explained as you may find them in the “point Information”
menu.
Point addr. select.
ADDRESS: 001
Ok. Canc
Point setting
•ADDRESS: 001-1
ZONE: 01
NAME: ROOM1
TYPE: SMOKE DETECTOR
SECTION: A-B
OUT OF SERVICE: NO
FAULT: NO
LED ON: NO
INPUT: DISABLED
SINGLE CONSENSE: NO
SERIAL NUM:002-00001
SW VERSION: 2.00
SUPERV.SMOK LEV: 130
NSUPER.SMOK LEV: 100
SMOKE (0-255): 003
DIRTY %: 000
EFFICIENCY %: 100
Esc. Pre. Next Mod.
