Page 67 of 91
Once the evacuation is initiated, the “Evacuation menu” changes, thus
allowing the user to terminate the function (button “3”).
13.4“EVACUATION” AND “EXTINGUISH” OUTPUTS
The control panel’s outputs and loops (I/O modules) can be programmed as “evacuation” or “extinguish” outputs
(see chapter 9.1.4). In this manner it is possible to command a extinguishing control unit or signal the evacuation
course or path with the light indicator signs to exit the building.
Evacuation men
0: EXIT
1: OUTPUTS SILEN.MOD
2: OUTPUTS RESTART
3: EVACUATION STOP
4: DELAYS TO ZERO
