9.1.4 Output setting
Inside a the “Output setting” menu it is possible to modify the output
parameters (for example in this picture there is a input/output module).
To modify the data use the arrows to move inside the control panel/loop and
modify with “Mod.” key if it is allowed.
The output display presents the disabled status of the input/output module
(for example).
If there are not any items, it is because those items are not available.
OUTPUT ADDRESS: it indicates the address and the loop of the output (no
mod.).
TYPE: it indicates the output type: “24 Vdc”, “SIREN”,
“FAULT”, “CONTR.PANEL OUT.” and “LOOP OUTPUT”
(no mod.).
DEVICE: output device type (no mod.):
“PWR SUPPLY.”: fixed output of power supply;
“SUPERV.RELAY”: supervisory relay output;
“RELAY”: no supervisory relay output;
“OPEN COLL.”: open collector output.
OUT OF SERVICE: it indicates if the output is in out of service (mod. YES
or NO).
FAULT: it indicates if the output is fault (no mod.).
TEST RUN: it permits to run a output activation test (mod.: YES or
NO).
ACTIVATION: it permits to activate the output (mod.):
“NO”: the output is not enabled;
“STATUS”: the output is enabled if anybody conditions
are true; it is possible to set some formulas for this
modality (OR-OR, OR-AND, AND-AND);
“ZONE REPETITION”: the output is activated if a zone
of a loop goes to fire alarm;
“FORMULA”: no available.
SILENT MODE: it sets up the possibility to manual silence the output,
without that the user must do the fire restoration
operation (mod.):
“NO”: the silent mode is possible to do only from “fire
restoration”;
“SINGLE”: in this command mode it is possible to
independently silence the output. To execute this
function, make reference to the chapter reported -
4.5.2;
“GLOBAL”: the user can silence the output through
“OUT.GLOBAL SILENCING” in the evacuation menu
(see 13.2);
ACTIV. DELAY s: it sets up the activation delay. If it is not set up, the
delay is null (mod. range: 000-600).
MAN.ALARM ACTIV: visible only if “ACTIV. DELAY” is not 0, it permits to
set up the output immediately activation in manual
alarm case from a push button. Normally this function
is disabled (mod.: YES or NO).
OUT ACTI.TIME s: it sets up the activation duration. If it is not set up, the
duration is unlimited until at restoration (mod. range:
000-600).
INVERT: it permits to invert the output function (mod.: YES or
NO).
Output setting
OUTPUT ADDRESS:001-1
TYPE: LOOP OUTPUT
DEVICE: RELAY
OUT OF SERVICE: NO
FAULT: NO
STATUS: DISABLED
TEST RUN: NO
•ACTIVATION: NO
SILENT MODE: NO
ACTIV. DELAY s: -
MAN.ALARM ACTIV: NO
OUT ACTI.TIME s: -
INVERT: NO
Esc. Pre. Next Mod.
