To activate the output status of the input/output module set yourself on the
activation line using the four arrows and type in “Mod.”.
The output activation of the input/output module allows different possibilities
of programming of the same module. The selection is made typing in “Mod.”
and it is viewed with a cross (x).
It is possible to activate an output if a particular zone of a loop is in fire
alarm. To do this, it is necessary to select “ZONE REPETITION”, to define
the loop and the range of the zone.
By means “MODE”, the logical formula can be set up for which the output
must be activated:
- OR-OR: the output is activated when at least a device of a zone goes
in fire alarm;
- OR-AND: the output is activated when at least an entire zone has all
the devices in fire alarm;
- AND-AND: the output is activated when all the zones have all the
devices in fire alarm;
The possibility to do activate an output through a formula, it is not available
now.
Output setting
OUTPUT ADDRESS:001-1
TYPE: LOOP OUTPUT
DEVICE: RELAY
OUT OF SERVICE: NO
FAULT: NO
STATUS: DISABLED
TEST RUN: NO
•ACTIVATION: FORMULA
FORMULA: NOT AVAILAB
SILENT MODE: NO
ACTIV. DELAY s: -
MAN.ALARM ACTIV: NO
OUT ACTI.TIME s: -
INVERT: NO
Esc. Pre. Next Mod.
Output setting
OUTPUT ADDRESS:001-1
TYPE: LOOP OUTPUT
DEVICE: RELAY
OUT OF SERVICE: NO
FAULT: NO
STATUS: DISABLED
TEST RUN: NO
•ACTIVATION: STATUS
TECHNOLOG.ALARM [ ]
FIRE.PREALARM [ ]
FIRE.ALARM [ ]
EVACUATION [ ]
EXTINCTION [ ]
FAULT [ ]
OUT OF SERVICE [ ]
SILENT MODE: NO
ACTIV. DELAY s: -
MAN.ALARM ACTIV: NO
OUT ACTI.TIME s: -
INVERT: NO
Esc. Pre. Next Mod.
Output setting
OUTPUT ADDRESS:001-1
TYPE: LOOP OUTPUT
DEVICE: RELAY
OUT OF SERVICE: NO
FAULT: NO
STATUS: DISABLED
TEST RUN: NO
•ACTIVATION: ZONE REP
MODE: OR-OR
LOOP REPETITION: 1
1st ZONE REPET.: 01
LAST ZONE REPET.: 01
SILENT MODE: NO
ACTIV. DELAY s: -
MAN.ALARM ACTIV: NO
OUT ACTI.TIME s: -
INVERT: NO
Esc. Pre. Next Mod.
