FDP EX-CPL - PART 13 EVACUATION; 13.1 DETAILS

Page 65 of 91
Rev. 4.
2
0
13.1DETAILS
The control panel allows to manage the functions of evacuation / extinguish which can be manually activated from
the panel itself or directly when a fire alarm occurs.
The settings of the evacuation are run within the “Evacuation setting” (see chapter 10.3).
The evacuation phase can be subdivided into 4 parts:
1) FIRE ALARM: whenever the control panel detects an alarm, fire type; it will go into “Fire alarm”
status.
2) EVACUATION: following a pre-set delay given by the initial settings for a fire alarm detection, the
evacuation procedure is initialized. The internal buzzer and all outputs/exits set up
as evacuation are activated and a red led lights up “evacuation” is lit and
signalled.
3) EXTINGUISH: following a pre-set delay given from the initial settings of the evacuation procedure,
the evacuation process comes to an end to make way for the extinguishing
procedure. The internal buzzer and all outputs dedicated to the extinguishing
become active, while the outputs with evacuation function are turned off.
4) RESTORE: following a pre-set delay given by the initial settings of the extinguish procedure,
the extinguishing process will terminate. All outputs dedicated to the extinguish with
red led “evacuation” are turned off.
STATO CENTRALE Fire outputs Evacuation outputs Extinguish outputs
FIRE ALARM
On
Off Off
EVACUATION
On On
Off
EXTINGUISH
On
Off
On
RESTORE
On
Off Off
PART 13
EVACUATION
EVACUATION
EXTINGUISH
RESTORE
FIRE ALARM
