15.1.4 Heat detector
The heat rate-of rise detector has been designed to activate itself when the heat exceeds a previously fixed level
or when the speed with which this increment is produced is high, even though the scheduled level has not been
exceeded.
ADDRESS: the point and loop addresses (no mod.).
ZONE: the zone address of the point loop (mod., range value
1-63).
NAME: the name of the point (mod.).
TYPE: point type (no mod.).
SECTION: the section where the point is (no mod.).
O.OF SERVICE: it indicates if the point is in out of service (mod. YES or
NO).
FAULT: it indicates if the point is fault (no mod.).
LED ON: if YES the leds flash (mod. YES or NO).
INPUT: the input is activeable like only TECHNOLOGICAL type
(mod.).
SING.CONSEN.: it is used when the control panel is supervisory mode
and the zone of the point is enabled the "double
consent". If YES, when the detector go to alarm status,
the control panel go to fire alarm too. The possibility to
modify this function is given provided that there are at
least 2 points on the specific zone. If after deleting of a
point, the assigned zone at double consent has only
one installed point, this parameter value will read No
(mod. YES or NO).
SERIAL NUM: the serial number of the detector (no mod.).
SW VERSION: the software version of the detector (it is changed
through PC).
RATE-OF-RISE: if value is YES, the heat detector has rate-of-rise
function too (no mod.).
SUP.TEMP LEV: the temperature level in supervisory mode. This level
refers at the TEMP. value (mod. Range: 40-70).
Beyond this value, the alarm goes active.
NSUP.TEMP LEV: the smoke level in no supervisory mode. This level
refers at the TEMP. value (mod. Range: 40-70).
Beyond this value, the alarm goes active.
TEMP. °C: it indicates the temperature measure from the detector
(no mod.).
Point setting
•ADDRESS: 001-1
ZONE: 01
NAME: ROOM1
TYPE: HEAT DETECTOR
SECTION: A-B
OUT OF SERVICE: NO
FAULT: NO
LED ON: NO
INPUT: DISABLED
SINGLE CONSENSE: NO
SERIAL NUM:002-00001
SW VERSION: 2.00
RATE-OF-RISE: NO
SUPERV.TEMP LEV: 058
NSUPER.TEMP LEV: 056
TEMP. °C: 25.32
Esc. Pre. Next Mod.
