15.3.7 Programmed I/O Module for bathroom alarm
If the I/O module of BATHROOM input, the output module is rendered un-accessible through its programming and
becomes active whenever the module reveals an input alarm signal.
JUMPER
RESTORATION BUTTON
27K ohm
POWER SUPPLY
+ -
The bathroom alarm is associated to the technological alarm, specifying on the display the original source of
alarm.
