7.3.3 Points removal (options)
In this menu different options to remove the points can be selected:
“SELECTED POINT”: to remove one only point;
“SELECTED ZONE”: to remove all the points placed in a zone;
“SELECTED LOOP”: to remove all the points belonging to a loop.
Use the four arrows to set oneself on the line with show the type of address
assignment the user wants to select and confirm with “Sel.”. Type in
“Canc” to return to the “Point menu”.
7.3.4 Loop selection
Whatever the previous selection may be, the belonging loop of the point or
the zone must be selected.
Select the “Loop” to programme and confirm with “Sel.”, use the four
arrows to set oneself on the line that shows the loop the user wants to
programme and select and confirm with “Sel.”. Type in “Canc” to return to
the “Point menu”.
7.3.5 Point address selection
Should the user select to remove a single point, type in the point address to
remove. Through the numerical keyboard it is possible to select the address
of the point.
Confirm the removal selection with “Ok” the control panel begins the
research and removes the selected point. Select “Canc” to return to the
“Point menu”.
7.3.6 Zone address selection
Should the user select to remove a zone of a loop, type in the zone address
to remove. Through the numerical keyboard it is possible to select the
address of the zone.
Confirm the removal selection with “Ok” the control panel begins the
research and removes the points of the selected zone. Select “Canc” to
return to the “Point menu”.
Point addr. select.
ADDRESS: 001
Ok
.
Canc
Points removal
•SELECTED POINT
SELECTED ZONE
SELECTED LOOP
Sel. Canc
Loop selection
•LOOP 1
LOOP 2
LOOP 3
LOOP 4
Sel. Canc
Zone address select.
ADDRESS: 01
Ok. Canc
