64
© Ferno s.r.l. Rel.05042024
XT Series Extrication Devices
117A
1
2
3
4
5
117B
117C 117D
Fasten the side straps by passing them through the plastic slots of the transverse restraint following the same procedure as for
the upper strap (Figure 117).
Figure 117 - Fitting the side straps of the triangular head immobiliser
Figure 118 - Triangular head immobiliser correctly installed
