XT Series Extrication Devices
6.3.3 QHI chin strap assembly
6.3.4 Assembling the restraints
1
2
3
4
5
Insert the strap of the chin strap into one of the two plastic slots
on the head-end oat, so that the closure of the bag remains
facing upwards. The chin strap can be tted either on the right or
left side of the board, depending on the operator's preference.
Once the strap is inserted into the plastic slot, fold it around
it, bringing the ap in the direction of the bag as shown in
Figure 104.
Figure 104 - Chin strap insertion
105B 105C105A
Insert the end of the strap inside the buckle and complete the
fastening as shown in Figures 105A, 105B and 105C.
Figure 105 - Chin strap fastening steps
Figure 106 - XT Floating restraint conguration before and after assembly
12
10
5
7
9 8
