66
© Ferno s.r.l. Rel.05042024
XT Series Extrication Devices
6.3.8 Assembling the auxiliary handles
Figure 122 - Fixing the auxiliary handles
The red carrying handles are removable and independent, so they can be moved as required.
They can operate directly on the board by using any available hole, or they can be mounted on other previously installed
auxiliary handles, in order to lengthen them and allow an extrication manoeuvre even on large builds.
To attach the red handles, follow the xing procedure with cow hitch (Figure 122A and 122B).
122A
122B
