XT Series Extrication Devices
4.3.3 Triangular head immobiliser assembly
In order to apply the triangular head immobiliser correctly, follow these instructions:
1. Insert the upper strap of the triangular head immobiliser into the hole no. 1 of the board, going from the front to the back of
the extrication device (Figure 28).
Figure 28 - Possible assembly congurations of the triangular head immobiliser
Figure 27 - Lifting tape application
27A 27B 27C
1
13 4
1
14 3
