XT Series Extrication Devices
5. Repeat the same operations with the other two straps in
the two side holes no. 3 and 14 or 4 and 13 (to identify the
holes, see Figure 4).
WARNING
Failure to complete the three fastening steps may
cause undesired loosening of the straps.
3.3.3 Chin strap assembly
The neoprene chin strap, stored in a special bag, can be
secured on the extrication device using side hole no. 14,
following the same instructions used for the application of
the triangular head immobiliser straps (to identify the hole
no. 14, see Figure 4).
Figure 3 - Chin strap assembly
3A 3B
Important
Both positions of the triangular head immobiliser on holes no. 4 and 13 or 3 and 14 are possible and ensure proper
stabilisation of the patient's head. The choice of set-up is at the discretion of the operator, who can choose the most
suitable version, depending on the contingency.
