OMNIA ST 3.2
9.3.2 Curve di temperatura per la modalità raffreddamento
CURVE CLIMATICHE (WTS) MODALITÀ RAFFREDDAMENTO
T4 (temperatura aria esterna) [°C]
-10 14 15 21 22 29 30 46
id Curva
climatica
Tipo di terminale
selezionato sul tele-
comando
Curve climatiche
impostate
T1S or T2S
(set point acqua impianto) [°C]
16,0 16,0 11,0 11,0 8,0 8,0 5,0 5,0 1
Fancoil C1
17,0 17,0 12,0 12,0 9,0 9,0 6,0 6,0 2
18,0 18,0 13,0 13,0 10,0 10,0 7,0 7,0 3
19,0 19,0 14,0 14,0 11,0 11,0 8,0 8,0 4
20,0 20,0 15,0 15,0 12,0 12,0 9,0 9,0 5
21,0 21,0 16,0 16,0 13,0 13,0 10,0 10,0 6
22,0 22,0 17,0 17,0 14,0 14,0 11,0 11,0 7
23,0 23,0 18,0 18,0 15,0 15,0 12,0 12,0 8
20,0 20,0 18,0 18,0 17,0 17,0 16,0 16,0 1
Riscaldamento a
pavimento radiante o
radiatore
C2
21,0 21,0 19,0 19,0 18,0 18,0 17,0 17,0 2
22,0 22,0 20,0 20,0 19,0 19,0 17,0 17,0 3
23,0 23,0 21,0 21,0 19,0 19,0 18,0 18,0 4
24,0 24,0 21,0 21,0 20,0 20,0 18,0 18,0 5
24,0 24,0 22,0 22,0 20,0 20,0 19,0 19,0 6
25,0 25,0 22,0 22,0 21,0 21,0 19,0 19,0 7
25,0 25,0 23,0 23,0 21,0 21,0 20,0 20,0 8
4
6
8
1
0
1
2
1
4
1
6
1
8
2
0
2
2
2
4
-10 0 10 20 30 40 50
COOLING MODE (climatic curves set C1)
1
2
3
4
5
6
7
8
1 2 3 4
5 6 7 8
1
4
1
6
1
8
2
0
2
2
2
4
2
6
-10 0 10 20 3 0 40 50
COOLING MODE (climatic curves set C2)
1
2
3
4
5
6
7
8
1 2 3 4
5
6
7 8
Modo raffreddamento (curva climatica impostata C1)
Modo raffreddamento (curva climatica impostata C2)
Curva climatica 9 in modo ra󰀨reddamento impostabile da utente
La curva climatica 9 è definita tramite 4 parametri impostabili dall’utente (T4C1, T4C2, T1SETC1, T1SETC2, vedi “9.2 Tabella dei parametri di servizio” a pagina 51).
T4C1
T4C2
T1SETC
2
T1SETC1
T4
T
1S (T1S2)
fig. 40 - Curva climatica 9 in modo raffreddamento
