9 OVERVIEW OF THE UNIT
9.1 Disassembling the unit
The ground fault circuit interrupter must be a high-speed type breaker of 30 mA (<0.1 s).
Please use 3-core shielded wire.
NOTE
A
B
C
D
E
F
8.5 To finish the outdoor unit installation
insulate and fix the refrigerant piping and interconnection cable as follows:
A Gas pipe
B Gas pipe insulation
C Finishing tipe
D Liquid pipe
E Liquid pipe insulation
F Interconnection cable
OUTOOOR UNIT
POWER SUPPLY
OUTOOOR UNIT
POWER SUPPLY
1-phase 3-phase
L N
L N
LPS
FUSE
XT1
LPS
FUSE
L1 NL2 L3
C NBA
XT1
