84
EN
Cod. 3541V991 - Rev. 06 - 10/2022
OMNIA ST 3.2
3. TECHNICAL DATA AN PERFORMANCE
3.1 System technical data
-
Models
4 6 8 10 12 14 16 12T 14T 16T
UM
A7W35
Heating capacity nom
4,20 6,35 8,40 10,0 12,1 14,5 15,9 12,1 14,5 15,9
kW
Power input nom
0,82 1,28 1,63 2,02 2,44 3,15 3,53 2,44 3,15 3,53
kW
COP
5,10 4,95 5,15 4,95 4,95 4,60 4,50 4,95 4,60 4,50
W/W
Water flow rate
722 1092 1445 1720 2081 2494 2735 2081 2494 2735
l/h
Available static pressure
78 70 50 33 51 33 23 51 33 23
kPa
A7W45
Heating capacity nom
4,30 6,30 8,30 10,0 12,3 14,1 16,0 12,3 14,1 16,0
kW
Power input nom
1,13 1,70 2,16 2,67 3,32 3,92 4,57 3,32 3,92 4,57
kW
COP
3,80 3,70 3,85 3,75 3,70 3,60 3,50 3,70 3,60 3,50
W/W
Water flow rate
740 1084 1428 1720 2116 2425 2752 2116 2425 2752
l/h
Available static pressure
78 70 51 33 50 37 23 50 37 23
kPa
A7W55
Heating capacity nom
4,40 6,00 7,50 9,50 11,9 13,8 16,0 11,9 13,8 16,0
kW
Power input nom
1,49 2,03 2,36 3,06 3,90 4,68 5,61 3,90 4,68 5,61
kW
COP
2,95 2,95 3,18 3,10 3,05 2,95 2,85 3,05 2,95 2,85
W/W
Water flow rate
473 645 806 1021 1279 1484 1720 1279 1484 1720
l/h
Available static pressure
83 79 77 72 82 75 66 82 75 66
kPa
A35W18
Cooling capacity nom
4,50 6,50 8,30 9,90 12,0 12,9 13,6 12,0 12,9 13,6
kW
Power input nom
0,82 1,35 1,64 2,18 3,04 3,49 3,77 3,04 3,49 3,77
kW
EER
5,50 4,80 5,05 4,55 3,95 3,70 3,61 3,95 3,70 3,61
W/W
Water flow rate
774 1118 1428 1703 2064 2219 2339 2064 2219 2339
l/h
Available static pressure
77 69 52 34 53 45 39 53 45 39
kPa
A35W7
Cooling capacity nom
4,70 6,50 7,45 8,20 11,5 12,4 14,0 11,5 12,4 14,0
kW
Power input nom
1,36 2,17 2,22 2,52 4,18 4,96 5,60 4,18 4,96 5,60
kW
EER
3,45 3,00 3,35 3,25 2,75 2,50 2,50 2,75 2,50 2,50
W/W
Water flow rate
808 1118 1281 1410 1978 2133 2408 1978 2133 2408
l/h
Available static pressure
77 69 60 53 55 49 37 55 49 37
kPa
The values are referred to units without options and accessories.
Data declared according to EN 14511:
EER (Energy Efficiency Ratio) = ratio of the total cooling capacity to the effective power input of the unit
COP (Coefficient Of Performance) = ratio of the total heating capacity to the effective power input of the unit
A7W35 = source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C
A7W45 = source : air in 7°C d.b. 6°C w.b. / plant : water in 40°C out 45°C
A7W55 = source : air in 7°C d.b. 6°C w.b. / plant : water in 47°C out 55°C
A35W18 = source : air in 35°C d.b. / plant : water in 23°C out 18°C
A35W7 = source : air in 35°C d.b. / plant : water in 12°C out 7°C
Outdoor unit technical data 4 6 8 10 12 14 16 12T 14T 16T UM
Power supply 220/240-1-50 380/415-3-50 V-ph-Hz
Compressor type Twin Rotary DC -
N° compressors / N° refrigerant circuits 1 / 1 n°
Heat exchanger type
stainless steel brazed plates
-
Fans type
DC axial
-
N° fans 1 n°
Hydraulic fittings / liquid line 1/4” SAE / Ø 6,35 3/8” SAE / Ø 9,52 -
Hydraulic fittings / gas line 5/8” SAE / Ø 15,88 -
Refrigerant type R32 type
GWP 675 kg-CO2 eq.
Refrigerant factory charge * 1,5 / 1,01 1,65 / 1,11 1,84 / 1,24 kg / t-CO2 eq.
Refrigerant lines (max length / max difference in height) 30 / 20 m
SWL - Sound power level
Heating **
A7W35 55 57 59 60 64 65 68 64 65 68 dB(A)
A7W55 56 58 59 60 64 65 68 64 65 68 dB(A)
Max 60 61 61 62 65 65 69 65 65 69 dB(A)
Sil. 1 56 56 57 58 62 62 63 62 62 63 dB(A)
Sil. 2 53 53 55 55 56 56 56 56 56 56 dB(A)
SWL - Sound power level
Cooling **
A35W18 56 58 60 60 64 64 69 64 64 69 dB(A)
A35W7 56 60 60 60 65 65 69 65 65 69 dB(A)
Max 60 61 61 62 65 65 69 65 65 69 dB(A)
Sil. 1 55 57 57 58 62 62 63 62 62 63 dB(A)
Sil. 2 52 54 54 54 56 56 56 56 56 56 dB(A)
Max. current input 12 14 16 17 25 26 27 10 11 12 A
Net weight 58 77 96 112 kg
Packed unit weight
65 94 114 130
kg
* The factory refrigerant charge allows a maximum length of the refrigeration lines of 15 meters. The maximum length of the refrigeration lines is 30 meters: in this case it is necessary to integrate the charge during
installation.
** : SWL = Sound power levels, with reference to 1x10-12 W with unit operating in conditions:
A7W35 = source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C
A7W55 = source : air in 7°C d.b. 6°C w.b. / plant : water in 47°C out 55°C
A35W18 = source : air in 35°C d.b. / plant : water in 23°C out 18°C
A35W7 = source : air in 35°C d.b. / plant : water in 12°C out 7°C
Max = at maximum conditions in heating / cooling mode
Sil. 1 = if silent level 1 active in heating / cooling mode
Sil. 2 = if silent level 2 active in heating / cooling mode
The Total sound power level in dB(A) measured in compliance with ISO 9614 standards.
