Unit A(mm) B1(mm) B2(mm) C(mm)
4~16kW
≥3000 ≥2000 ≥150 ≥600
2) In case of installing multiple units in lateral connection per row.
Unit
A(mm) B1(mm) B2(mm) C(mm)
4~16kW
≥3000 ≥2000 ≥300 ≥600
7 INSTALL THE CONNECTING PIPE
7.1 Refrigerant piping
gas liqulid
1
2
4~16kW
Fig.7-1
≥500mm
≥500mm
＜1/2 H
B2
A
B1
C
H
Fig: 6-8
C
B1
＜1/2 H
B2
A
C
H
Fig: 6-7
