Ferroli OMNIA UE 3.2 User Manual

24
Assembly unit Assembly unit
Coding Coding
1
2
3
4
5
6
7
9
10
11
Power supply L3(CN200)
Power supply L2(CN201)
Power supply L1(L1)
Power supply N(CN203)
Reserved(CN211)
Power supply port for main control board(CN30)
Power filtering L1(L1’)
Power filtering L2(L2’)
Power filtering L3(L3’)
3) PCB C, filter board
PCB C 3-phase 12/14/16kW
PE1
PE2
PE3
CN202
CN201CN200CN203
CN204 CN205 CN206
CN212
CN211
CN8
CN213
CN214
CN30
2
5
4 3
6
13
12
7
8
9
10
11
14
15
1
16
12
8
13
14
15
16
Power supply port of 310VDC(CN212)
Ground wire(PE3)
Port for ground wire(PE1)
Port for ground wire(PE2)
Power supply port for Inverter module(CN214)
Port for FAN Reactor(CN213)
Port for communication with PCB B (CN8)
