PLEASE NOTE
In order to correct the byte swap, you need
only assign the appropriate I/O address to
each byte. Individual I/O assignment at bit
level is only necessary in special cases.
The following dialogue window shows the entries
required for swapping the assignment of the high
byte and the low byte (example: byte swap for
"Standard mode").
Fig. 4/15: Modifying the I/O assignment – example for Standard mode
VIFB6 - 03/05 4. Commissioning
9809c 4-35
