4.2 INTERBUS – BUS CONFIGURATION AND ADDRESSING
4.2.1 Bus configuration via the CMD software
This chapter describes as an example the main
steps which you will require in the CMD
software, in order to insert a Festo valve terminal
in your project. A general and comprehensive
description can be found in the relevant manual
for the CMD software. It is assumed here that
the user is already familiar with the information
in the CMD manual.
PLEASE NOTE
The software packages are subjected to modi-
fications which are not taken into account in
this manual.
The examples of screen displays used here
are taken from the CMD software version 4.
Further and current information can be found
in the manual for your CMD software.
VIFB6 - 03/05 4. Commissioning
4-16
9809c
