3.3.3 Connecting the INTERBUS interface
There are two connections on the node for the
INTERBUS. One of these connections is for the
incoming cable, the other is intended for the
outgoing bus cable.
Different INTERBUS modules and thereby differ-
ent connection and screening methods are used
depending on the application. Please observe
therefore the following differences on the remote
bus and on the installation remote bus.
INTERBUS
incoming
INTERBUS
outgoing
Fig. 3/16: Connecting the INTERBUS interface
