10 A
Operating
voltages
can be
switched off
sperately
External fuses
DC 24V
± 10%
PE
AC
230 V
3.15 A 24 V
Fuse for valves
(4 A, slow blowing)
Potential compensation
Connected
adapter cable
Earth cable
connection pin 4
designed for 12 A
Operating voltage
connection
Fuse for inputs/
sensors (2A)
0 V
Fig. 3/15: Example – connecting a common 24 V supply and
potential compensation (type 05)
