Address assignment of valve terminal
The address assignment of the outputs of a
modular valve terminal depends on the equip-
ment fitted on the terminal. A distinction is made
between the following equipment fitted:
• valves and digital I/O modules
• valves only
• digital I/O modules only.
The basic rules described below apply for the
address assignment of these fitting variants.
Following the basic rules, there is a detailed
example for both the type 03 and type 05
terminals.
PLEASE NOTE
If two addresses are assigned for one valve
location, the following applies:
•
lower-value address
⇒
pilot solenoid 14
•
higher-value address
⇒
pilot solenoid 12
VIFB6 - 03/05 4. Commissioning
9809c 4-9
