Copy this table for further calculations (type 05).
Table for calculating the number of inputs/outputs (type 05)
INPUTS
1. Number of 4-input modules ______
⋅ 4
2. Number of 8-input modules ______
⋅ 8
3. The 4 status bits are assigned automatically by the terminal
internally. They must be treated like inputs and must be
added to the intermediate sum
+
Total sum of inputs to be configured =
OUTPUTS
4. ISO sub-base modules for
• 4 valve locations 8 O
• 8 valve locations
*)
16 O
• 12 valve locations
*)
24 O
5. Number of electronic output modules _______
⋅ 4
+
Total sum of outputs to be configured =
*) Do not switch on more than 12 valves simultaneously
(the internal fuse will blow).
Σ O
+
Fig. 4/3: Calculating the number of inputs/outputs (type 05)
VIFB6 - 03/05 4. Commissioning
4-8
