The following diagrams explain the different
positions of the four status bits.
Equipment on valve terminal Available
address range
Addresses of the
status bits
Ident code Process data channel
1 No address
range for inputs
No status bits
available
2 or 3
2 or 3
2 or 3
2 or 2
16
32
48
64
0 ... 15
0 ... 31
0 ... 47
0 ... 63
12, 13, 14, 15
28, 29, 30, 31
44, 45, 46, 47
60, 61, 62, 63
Fig. 4/16: Position of the status bits in the Siemens mode
Equipment on valve terminal Available
address range
Addresses of the
status bits
Ident code Process data channel
1 No address range
for inputs
No status bits
available
2 or 3
2 or 3
2 or 3
2 or 2
16
32
48
64
0 ... 15
0 ... 31
0 ... 47
0 ... 63
4, 5, 6, 7
20, 21, 22, 23
36, 37, 38 39
52, 53, 54, 55
Fig. 4/17: Position of the status bits in the Standard mode
