3.1 SUMMARY OF INSTALLATION
System structure on the remote bus
The valve terminal type 03/05 is a 2-wire slave
on the remote bus.
The valve terminal reacts on the remote bus like
a bus terminal with integrated I/Os and must be
addressed accordingly.
PLEASE NOTE
•
Commissioning on the bus can only take
place when all slaves have been completely
connected and switched on together.
•
The valve terminal requires a 24 V DC
operating voltage. Separate supply for the
valve terminal outputs/valves is also
possible (e.g. EMERGENCY OFF circuit).
VIFB6 - 03/05 3. Installation
9809c 3-3
