Calculating the current consumption (typ 03)
The following table shows the calculation of the
total current consumption for terminal type 03.
The values given are rounded up. If you use
other valves or modules, you should consult the
appropriate technical specifications for their cur-
rent consumption.
Current consumption of electronic
components node and inputs type 03
(pin 1, 24 V ± 25 %)
Node
Number of simultaneously
occupied sensor inputs: _____x 0.010 A
Sensor supplies: ____x_____ A
(see manufacturer specifications)
+
+
Current consumption of electronic
components, node and inputs
(pin 1) max. 2.2 A
=
Current consumption of outputs type 03
(pin 2, 24 V ± 10 %)
Number of MIDI valve coils
(simultaneously under power): ____ x 0.055 A
Number of MAXI valve coils
(simultaneously under power): ____ x 0.100 A
Number of simultaneously activated
electric outputs: ____ x 0.010 A
Load current of simultaneously
activated electric outputs ____x_____ A
+
+
Current consumption of outputs
(pin 2) max. 10 A
Total current consumption
of valve terminal type 03 =
∑ A
∑ A
∑ A
∑ A
∑ A
0.200 A
∑ A
∑ A
∑ A
=
+
+
+
Fig. 3/8: Calculating the total current consumption of terminal type 03
