Operating status displays
Display with control panel protection
Lock
Display in Stop status or for 1.5 s when the START/STOP button is pressed.
Lock for the START/STOP and STATUS/TEACH buttons via PLC programming.
A change of operating mode is controlled exclusively by the PLC (see Chapter 4.3)
Fix
Block of the STATUS/TEACH button with the CheckKon configuration software
(Parameter “System/Operating modes/Bloc k of the Teach button = ...”). The Checkbox
can be started or stopped manually; a c hange to the Teach mode is not possible.
Acknowledgment of the message with the START/STOP button.
Fault signal
Details in Chapter A.1.2.
E...
Fault code for system faults 01 ... 99
F...
Warning 05
Display during the Teach procedure
1 o...
Memory module of the parts type and
number of the sample part orientation
during t he Te ach procedure.
1 ... 8
? ...
Selecting the memory module of the parts type 1 ... 9,a,b,c,d,e,f,g
C...
C-value
Maximum value of the scatter of c haracteristics for the current
feature whic h differs most
. 10: Sample parts are very similar in all features
, 30: Large scatter of at least one feature
0 ... 999
tool
Memory address assigned with measuring tool or optimized Teach data ( CheckOpti)
