Operating status displays
Display during the test procedure
15
Tolerance value for the current parts type
1st number: Number of the parts type
2nd number: To lerance in %
1 ... 9,a,b,c,d,e,f,g
0 ... 20
A...
Inspection part deviation: The smaller the value, the more
accurately the inspection par t corresponds to the registered
sample pa rt s.
≤100: Good part
>100: Reject part
0 ... 999
#...
The smaller the v alue, the more reliably the inspection part
orientation will be recognized.
<100: Inspection part orientation can be assigned
>100: Inspection par t orientation c annot be assigned clearly
0 ... 999
Full
Status of the buffer zone (signal from buffer zone sensor)
cFul
Preselected counter setting reached
Display of the conveyor speed
The operating system version ...E is required to display the conveyor speed [mm/s].
– Press the TEACH/STATUS button while the conveyo r equipment is running.
Tab. A/5: Display
