1. S ystem summary
1-11
Festo P.BE-CB-COMP-EN en 1102d
1 Transporting
device
2 Sensor 1
1
A
B
2
Fig. 1/2: Buffer zone check
1 Transporting
device
2 Sensor 2
3 Sensor 1
A
B
OB
3
2
1
Fig. 1/3: Buffer zone check with hysteresis
