2. Fitting and commissioning
2-16
Festo P.BE-CB-COMP-EN en 1102d
Before the Checkbox is switched on the first time, make sure
that you have completed the following steps:
1. mounting of the conveyor device
2. mounting of the Checkbox to the conveyor device
3. connection of operating voltage to the 24 V DC connection
4. connection of external components, if required
Observe the instructions on connecting external
components in the followi ng chapters:
– Chapter 3.2 “Actuators”
– Chapter 3.3 “Buffer zone sensors, small parts
conveyor”
– Chapter 3.5 “Encoder”
– Chapter 3.6 “Higher-order controller”
Warning
Check to see whi ch measures are necessary for putting
your machine/system in a safe state when it is switched on
and off. Observe that movements of the connected actuat-
ors can cause injury to people and damage to property, for
example
• when the conveyor device is moved to its basic position
when the power supply is switched off
• the conveyor device starts automatically if controlled by
the Checkbox when the Checkbox starts.
In order to prevent the conveyor device from starting auto-
matically when the operating voltage is switched on:
• Select in CheckKo n [Window] [System parameters] Z
System Z Operating modes ... Z Automatic start after
power supply on = no (factory setting).
