5. Testing parts
5-6
Festo P.BE-CB-COMP-EN en 1102d
Terminate the test mode when all settings have been com-
pleted and the checked parts have been graded reliably with
regard to orientation and quality .
Stop
8. Press the button START/STOP, in order to switch the
Checkbox into the Stop status.
9. Conclude the diagnostic mode. Close CheckKon (and
CheckOpti).
10. Remove the diagnostic cable from the DIAG connection
and seal the connection with the protective cap supplied.
