Festo Controller CECC
47
6. Select another/unoccupied connection for a further IO-Link device in the device window (only with
CECC-LK, max. 4). The "Plug Device" dialog must be left open for this.
7. If necessary, repeat from step 3 onwards to plug further IO-Link devices (only with CECC-LK, max. 4).
8. Close the dialog by clicking the "Close" button.
A digital sensor or actuator can also be connected to the IO-Link master port instead of an IO-
Link device.
• Select "Digital_Input" for a sensor
• Select "Digital_Output" for an actuator
Figure: Example of the CECC-LK with 4 plugged IO-Link master ports
The names in the device window can be changed.
• Click a previously highlighted device to switch to editing mode (not double-click).
