3 Holder systems
16 © Festo Didactic 759614
3.1.1 Design and function
The EduTrainer
®
Compact holder system makes it possible to combine controllers from various
manufacturers with simulation plates and 4 mm connection plates. Holder systems are available in three
different sizes.
3.1.2 Commissioning
Connect the EduTrainer
®
Compact to a 24 V DC power supply using laboratory cables with 4 mm safety
sockets.
3.1.3 Technical data
Electrical/mechanical
Operating voltage 24 V DC
Output voltage Corresponds to input voltage
Fuse 3.15 A slow-blow
Output current Max. 4.5 A
Connection
4 mm safety sockets
3-pin plug for internal power supply to the modules
Size 1 171 x 243 x 82 mm (PLC plus 9 HP)
Size 2 171 x 365 x 82 mm (PLC plus 33 HP)
Size 3 171 x 487 x 82 mm (PLC plus 57 HP)
Maximum PLC width/height 160 mm/130 mm
CE marking
in accordance with low voltage directive
in accordance with EU-EMC Directive
Interference emission tested to EN 61000-6-3
Interference immunity tested to EN 61000-6-1
Subject to change
