6.2 Commissioning
1. Connect the inputs/outputs to the PLC using a flat cable:
– SV2: Siemens S7 (16-pin)
– SV1: Other controller types (10-pin)
2. If using modules in parallel, these can be connected via the free insulation-displacement connector SV1
or SV2 using flat cables.
3. Connect the 24 V power supply by means of the 3-pin connector SL1 or SL2.
4. The jumper JP1 defines that the input module is directly supplied via 24 V.
5. Screw the 19-inch module into the frame.
6.3 Technical data
Electrical/Mechanical
Operating voltage 24 V DC
Input voltage 0 V – operating voltage
Input impedance See PLC manual
Current rating Max. 4.0 A
Connection 4 mm safety sockets
Front-plate width 6 HP
Subject to change
6.4 Contact allocation table
Pin SV1 SV2 Pin SV1 SV2
1 L1+ 0V 9 I7 L1+
2 I0 I7 10 0V I3
3 I1 0V 11 — L1+
4 I2 I6 12 — I2
5 I3 0V 13 — L1+
6 I4 I5 14 — I1
7 I5 0V 15 — L1+
8 I6 I4 16 — I0
